Horizontal Spout Premade Bag Packing Machine

This series is specially designed for the needs of stand-up pouches with straight suction nozzles, and has flexible functional applications, such as adding hanging holes, special shapes, zippers, suction nozzles and other functions, which are widely used in salt, lubricants, beverages, juice, yogurt, sauce , edible oil, washing series and other packaging types.

DetailsParameterVideoApplication

（1） Premade Pouch Stack	（2）Flip-Out Pouch-Picking Unit	（3）Pouch Opening	（4）Air Flushing	（5）Filling I
（6） Filling II	（7）Vibrator	（8）Spout Inserting	（9）Heat Sealing	（10）Cool Sealing
（11）Finished Product

Horizontal Spout Premade Bag Packing Machine

The filling system is just for your reference. We will offer you best solution according to your product mobility, viscosity, density, volume, dimensions etc.

A. Powder Packing Solution

Servo Screw Auger Filler is specialized for powder filling such as nutrients powder, seasoning powder, flour, medicinal powder etc.

B. Liquid Packing Solution

Piston Pump Filler is specialized for liquid filling such as water, juice, laundry detergent, ketchup etc.

C. Solid Packing Solution

Combination multi-head weigher is specialized for solid filling such as candy, nuts, pasta, dried fruit and vegetable etc.

D. Granule Packing Solution

Volumetric Cup Filler is specialized for granule filling such as chemical, beans, salt, seasonings etc.

E. More Packing Solution

For more solution, welcome to contact us.

Horizontal Spout Premade Bag Packing Machine Bag Type

Model	SG-180C	SG-360DC
Maximum Packing Volume	1000ml	1000ml
Max Pouch Size	160mm*310mm	160mm*260mm
Min Pouch Size	60mm*80mm	90mm*110mm
Packing Speed	30-60ppm	60-120ppm
Air Consumption	200NL/min	500NL/min
Input Power	2.6kw	6kw
Working Power Supply	AC 380V 50Hz	AC 380V 50Hz
Equipment Weight	800kg	2000kg
LWH	21909701400mm	41009701400mm

Horizontal Spout Premade Bag Packing Machine
